3000 SERIES

Optimize Value Recovery for Automatic Grading

The chroma+scan 3000 Series offers high-density 3D lumber profiling at fast scan rates for transverse applications. The chroma+scan 3000 platform is scalable, and allows you to apply 2D color vision or tracheid detection to optimize value recovery.


Quick Specs



MODEL 3155 3250 3350
Profile Scan Rate (Hz) 2000 2500 2000
Resolution X (mm) 8.000 8.000 8.000
Resolution Z (mm) 0.127 0.127 0.127
Color Profile Resolution XY (mm) N/A N/A 1.0 x 0.5
Tracheid Scan Rate (Hz) N/A 500 N/A
Tracheid Resolution X (mm) N/A 8.00 N/A
Field of View (mm) 610 610 610
Clearance Distance (CD) 508 508 550
Measurement Range (mm) 203 203 150
Laser Lines 4 4 4


MECHANICALS
