3200 SERIES

Large Field of View 3D Snapshot Sensor

Use Gocator 3210’s blue-LED structured light technology and wide field of view for full field inspection of large targets (e.g., automotive components and assemblies).

  • Fast scan rate (6 Hz w/ acceleration)

  • 2-megapixel stereo camera minimizes occlusions

  • Large field of view (FOV) up to 100 x 154 mm

  • Pick-and-place friendly for robotic/stationary inspection applications

3200 snapshot.jpg

Quick Specs


Model 3210

Resolution XY (µm) 60-90

VDI/VDE Accuracy (µm) 35

Field of View (mm) 71 x 98 - 100 x 154

Clearance Distance (CD) (mm) 164

Measurement Range (mm) 110

MECHANICALS

G1300 Connector_drawing_9.png

90 Degree Connector / Straight Connector
