2100 SERIES

Entry-Level 3D Laser Line Profile Sensors

Use Gocator® 2100 for cost-effective inline quality inspection applications where the highest resolution is not required.

  • VGA imager. 640 points per profile resolution

  • Field-of-view up to 1260 mm

  • Measurement range up to 1350 mm


Quick Specs


Model 2120 2130 2140 2150 2170 2175 2180
Resolution X (mm) 0.028 0.088 0.19 0.3 0.55 0.51 0.75
Resolution Z (mm) 0.0018 0.006 0.013 0.019 0.055 0.175 0.092
Field of View (mm) 18-26 47-85 96-194 158-365 308-687 324-1010 390-1260
Clearance Distance 40 90 190 300 400 650 350
(mm)
Measurement Range 25 80 210 400 500 1350 800
(mm)

MECHANICALS

G1300 Connector_drawing_9.png

90 Degree Connector / Straight Connector
